The Classics electrically conductive RFI gaskets

coated foam round strip

The easy to install foam round strips made from conductive coated silicone are especially soft and elastic and feature good compression sets. The extensive standard program is readily available in endless lengths as yard goods. We can also manufacture customer-specific lengths, cross-section designs as well as pasted O-rings for you.
Typical application fields are housing gaskets etc.


NEUSIL
Standard Dimensions

line



 Coating: standard:  1442, electrically conductive
 Core: silicone foam, non electrically conductive




Item-no. 1D A tolerance
N-xxxx-SS-1,5 1,50± 0,18
N-xxxx-SS-1,8 1,80± 0,20
N-xxxx-SS-2,0 2,00± 0,20
N-xxxx-SS-2,3 2,30± 0,20
N-xxxx-SS-2,5 2,50± 0,25
N-xxxx-SS-2,8 2,80± 0,25
N-xxxx-SS-3,0 3,00± 0,25
N-xxxx-SS-3,3 3,30± 0,25
N-xxxx-SS-3,5 3,50± 0,25
N-xxxx-SS-3,8 3,80± 0,30
N-xxxx-SS-4,0 4,00± 0,30
N-xxxx-SS-4,3 4,30± 0,30
N-xxxx-SS-4,5 4,50± 0,30
N-xxxx-SS-4,8 4,80± 0,35
N-xxxx-SS-5,0 5,00± 0,35
N-xxxx-SS-5,3 5,30± 0,35
N-xxxx-SS-5,5 5,50± 0,35
N-xxxx-SS-6,0 6,00± 0,35
NEUSIL material selectionmaterial description (look here)¹
¹ xxxx
Insert wildcard in the desired article number
1440nickel
1441Ag/glass
1442Ag/Cu
1443Ag/Al
1444Ag

Zu ihrer Information
D o w n l o a d PDF-Logo
storage instructions    Lagerhinweise  -  deu_schnuere.pdf Storage instruction  -  eng_strips.pdf
